Hunting for Hidden API Endpoints Using Katana and Hakrawler

Crawling a target I thought I knew — with Katana, hakrawler, waybackurls, and unfurl — surfaced a hidden /HelpApi/ endpoint and an IDOR leaking users' PII.


        Crawling a target I thought I knew — with Katana, hakrawler, waybackurls, and unfurl — surfaced a hidden /HelpApi/ endpoint and an IDOR leaking users' PII.

Good day! I hope you’re doing well.

In bug bounty, never say: “This idea is silly to try; the result will be nothing.” Bug bounty hunting is essentially black-box testing — you have to keep poking at your target until something turns up.

الحمدلله والصلاة والسلام على سيدنا محمد اللهم انصر إخواننا في فلسطين

The target I was hunting already had several bugs I’d found and reported before. I used to tell myself, “I know everything about this website. If something new appears, I’ll spot it.”

Then I watched Hussein Daher’s talk, where he mentioned he relies heavily on Katana to crawl websites.

Web crawling, in the context of bug bounty, is the process of automatically navigating a website’s structure to discover resources such as pages, files, and scripts — by following links and examining directories to build a map of the site’s content.

I was initially refusing to use it on this program, thinking “It’ll be useless — I already know all the URLs.” But I decided to give it a try, alongside another great tool: hakrawler by hakluke.

First, I grabbed the archived URLs:

echo "http://target.com" | waybackurls | anew urls.txt

That gave me about 71,000 URLs.

waybackurls output — around 71,000 URLs

Then I ran all of them through Katana and hakrawler:

cat urls.txt | katana | hakrawler -d 3 | anew katana.txt

Katana has a lot of useful options, but since I was new to it I just ran it as-is. The -d flag in hakrawler sets the crawl depth (default is 2).

I left it running for about two days and ended up with 41,000 URLs in katana.txt.

katana.txt — around 41,000 URLs

A lot of these were unique in their paths but not in their subdomains, for example:

https://sub1.target.com/account
https://sub2.target.com/account

I only wanted unique paths, so I used unfurl by Tomnomnom to filter them:

cat katana.txt urls.txt | unfurl format %p | anew paths.txt

That left me with around 5,500 unique paths. unfurl can also pull out subdomains, so I grabbed the unique ones too:

cat katana.txt urls.txt | unfurl format %d | anew subs.txt

Going through paths.txt, I initially found nothing new — every path looked familiar. But I was wrong. One path caught my eye that I’d never seen before:

/HelpApi/

Opening it on the main domain (target.com/HelpApi/) returned the full API documentation for the website.

Exposed /HelpApi/ documentation

Now I had plenty to explore. One endpoint stood out:

/account/subscribe?groupId=123

I could smell an IDOR. The request returned the users in group 123 — and by changing the groupId, I could read users from other groups. The exposed data included email addresses, roles, phone numbers, and other private information.

I reported it as a PII (Personally Identifiable Information) disclosure. Alhamdulillah, it was triaged the next day, fixed, and rewarded.

Report triaged and rewarded

I hope you enjoyed this one. Yes, it’s a simple bug — but it came after a couple of days of recon. Huge thanks to Hussein Daher for his talk; I highly recommend watching it.

Thanks for reading. Cheers :)
